Double Steel Tape PE sheath Armored FOC Cable GYTS53

Place of Origin : Shenzhen,China

Brand Name : GT-Link

Certification : ISO,CE,RoHS,GGS

Model Number : GT-GYTA53

Installation : Direct-buried Cable

Strength Member : Steel Tape

Sheath Material : PE,LSZH,PVC,TPU

Fiber Number : 12~288

Package : 2KM/3KM

Operating temperature : -40~+60°C

OEM : Available

Model Type : Double Jackets

Loose Tube Material : PBT

Fiber Type : single mode or multi mode

Central Strength Member : Steel Wire

Water-blocking Material : YES

Cable Filling Compound : YES

MOQ : 10km

Price : USD0.1~0.5/M

Packaging Details : 1.wooden roller with test report 2.1000m/roller,2000m/roller,3000m/roller,4000m/ro

Delivery Time : 5-15days

Payment Terms : L/C T/T Western Union

Supply Ability : 1000 Kilometer/Kilometers / Week

Shipping Port : Shenzhen

Contact Now

Double Steel Tape PE sheath Armored FOC Cable GYTS53

Description:

The fibers, 125μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire, sometimes sheathed with polyethylene (PE) for cable with high fiber count, locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. An corrugated steel tape is applied around the cable core. which is filled with the filling compound to protect it from water ingress. Then the cable core is covered with a thin PE inner sheath. After the PSP is longitudinally applied over the inner sheath, the cable is completed with a PE outer sheath.

1.Technical characteristics

1.The loose tube material has good water-resistant properties and higher intensity.
2.special jelly filled in the loose tube provides the fibers with critical protection
3.excellent crush resistant performance and flexible performance
4.the out PE sheath provides good anti-UV radiation performance

2.Cable Construction Parameter:

Fiber number

230

3236

3860

6272

7484

Tube outer diameter(mm)

1.9

1.9

2.3

2.3

2.3

Tube number

5

6

5

6

7

Max. fiber number per tube

6

6

12

12

12

Cable outer diameter(mm)

10.3

10.6

11.1

11.8

12.5

Cable weight(Kg/Km)

110

130

135

160

165

Fiber number

8696

98108

110120

122132

134144

Tube outer diameter(mm)

2.3

2.3

2.3

2.3

2.3

Tube number

8

9

10

11

12

Max. fiber number per tube

12

12

12

12

12

Cable outer Diameter(mm)

13.2

13.9

14.6

15.4

16.1

Cable weight (Kg/Km)

180

200

215

235

250

3. Fiber properties (The properties of SM optical fiber ITU-T Rec.G.652D)

Items

Specified Values

Fiber Type

G.652 Single-mode fiber

Mode Field Diameter@1310nm

9.2±0.4μm

Cladding Diameter

125.0±1.0μm

Mode Field Concentricity Error

≤0.5μm

Cladding No Circularity Error

1.0%

Cut-Off Wavelength

λcc(test 20m cable+2m fiber) ≤1260 nm

Attenuation Coefficient

1310nm

1550nm

≤0.36 dB/km

≤0.22 dB/km

Dispersion Coefficient

1288-1339nm≤3.5ps/nm.km

1270-1360nm≤5.3ps/nm.km

1550nm≤18ps/nm.km

1625nm≤22ps/nm.km

Zero Dispersion Wavelength

1300nm-1324nm

Zero Dispersion Slope

≤0.09ps/nm2.km

PMD­Q*

≤0.2ps/km1/2

Coating Diameter

245±10μm

Proof Test

100kpsi0.7Gpa
